CJR Performance Honda CBR600RR ECU Mail-In ECU Flash
The best way to derestrict your Honda CBR600RR is with our Custom CJR Performance CBR600RR ECU Flash! We spent countless hours on the dyno with individual cylinder tuning of various air filters, velocity stacks, and exhaust combinations. From there we headed to the track and have completely optimized the ECU for the 2007-2008, 2009-2012, and 2013+ models. Each ECU is handled with care and custom suited to match your modifications and riding style.
This ECU flash can be used solo or with an existing piggyback fuel controller such as a Power Commander 5 or 6, great for those running additional modifications outside of our custom ECU Flash options.
(ECU MAIL IN INSTRUCTIONS LOCATED AT THE BOTTOM OF THIS PAGE)
Features and Custom Options Include -
- Custom Gear by Gear Ignition Timing - For optimal performance across the entire RPM range in every gear.
- Custom Individual Cylinder Tuning - On our test exhaust systems we weld in an O2 bung on each header coming out of the cylinder head for custom tuning all 4 cylinders, opposed to just using the single O2 found at the collector. With this we are able to optimize each cylinder for a very refined target air/fuel. This is especially important when paired with aftermarket velocity stacks which can cause a range of lean/rich conditions per each cylinder. During testing/tuning we revise fueling for every throttle position along with updated manifold pressure maps to allow the best tip-in throttle and optimal fueling across the entire RPM range.
- Revised Start of Injection Timing - For additional improved throttle response and performance across the entire RPM range.
-
Revised Injector Balance - With revised injector balance between the lower primary injectors and upper shower injectors, this helps even further improve top end performance to continue pulling strong where the stock settings fall off.
- Optional Custom RPM Limit - Keep OEM rev limit or increase +500 RPM which is safely recommended with aftermarket velocity stacks.
- Custom Fan Temps - Optional custom change from factory's 217/239F settings.
- Disable Exhaust Servo (Optional) - (On for Stock or Slip On Exhaust - Off for Cat/Servo delete and Full System Exhaust)
-
Disable O2 sensor (Optional)
- Disable Knock Sensor (Optional)
- Disable Honda Eletronic Steering Damper (HESD) Fault Code (Optional)
-
Optional Engine Braking Strategy / Deceleration Fuel Cut (DCFC)*-
- Heavy Engine Braking - Stock + DCFC On - No changes in deceleration compared to OEM, expect jerky on/off throttle and heavy engine braking when coasting to a stop.
- Medium Engine Braking - Stock + DCFC Off - This will provide slightly less engine braking than stock, with slightly smoother on/off throttle transition at all RPM ranges.
- CJR Custom Engine Braking - This setting was built and refined at the track and used on our current race/track builds, this setting has slightly less engine braking than the medium setting when completely off throttle. This setting also has a lot of revised changes in the 1%-25% throttle area to allow extremely smooth throttle control. Perfect for buttery smooth transitions of on/off throttle changes during switchbacks and at full lean, suited perfectly for the track.
-
*Decel Fuel Cut (DCFC) = Continues to allow fuel over-run on deceleration which in turn allows for smoother On/Off throttle inputs and slightly less engine braking. Stock (DCFC ON) will shut all injectors off when decelerating at 0% throttle. With DCFC OFF, the injectors will continue to flow when decelerating at 0% throttle.
-
Add Launch Control (Requires Full System Exhaust / Deleted Ex Servo)
- Allow bike warmup, when ready for LC key on, start the bike, click from neutral into 1st gear and while holding the clutch. Hold throttle wide open to a set target RPM, and you're ready to launch. - Custom Launch Control Rev Limit - Custom choose your preferred launch RPM.
Available Part Numbers for Launch Control - 2013-2026* CBR600RR (PC40)
- 38770-MJC-N31
- 38770-MJC-A01
- 38770-MJC-M51
- 38770-MJC-L01
*Not yet available for 2021+ Japan/Euro CBR600RR (PC69)
Availability Part Numbers for Launch Control - 2007-2008 / 2009-2012 CBR600RR's
- 38770-MFL-A42
- 38770-MFJ-A01
- 38770-MFJ-A02
- 38770-MFJ-F03
- 38770-MFJ-D04
- 38770-MFJ-L01
- 38770-MFJ-L02
*If your ECU part number is not listed, expect an additional 2-3 day turnaround time.
*For Race Competition Use ONLY
NOTE: For bikes equipped with fuel cut based quick shifters - It is recommended to have a standalone unit like the Dyonjet Standalone Quickshifter. A QS that cuts fuel to both the upper and lower injectors, or ignition based QS. When adjusting the injector balance to the upper injectors for wide open throttle, the fuel cut on most quick shifters (piggyback based) applies only to the lower injectors. This becomes an issue where the quick shifter tries to cut fuel to an injector that is not sending much fuel to begin with.
How to order:
- Step 1 - Fill Out Modifications / Waiver Form. (Form will pop up during checkout)
- Step 2 - Take the ECU out of the bike and mail your ECU to the following address - (Please email your tracking number if available to CJRPerformanceLLC@gmail.com)
CJR Performance
5825 E Hwy 163
Columbia MO 65201
- Step 3 -ECU flashing is shipped within 24-48hrs of the order being received.
- Generally total turnaround time with UPS ground is 5-7 business days (2-3 days to us, 24-48hr flash time, 2-3 days return shipping)
For existing customers looking to change tunes, follow this link - https://www.cameronjonesracing.com/custometuning/p/tuneupdate
NOTE -
*If a mail-in ecu flash is purchased with other products, the other products will be shipped back in the same package the newly flashed ecu that is being mailed back to you.
Tune Revisions -
6/19/2025 - Updated ECU Database
6/19/2025 - Updated Slip-On Fuel Maps
6/19/2025 - Updated for Launch Control to be available for Full System Exhaust ONLY
6/23/2025 - Revised Decel Engine Braking Options for Drop-Down Menu. Updated medium option, removed the light engine braking option, replaced light with our CJR custom option.
DISCLAIMER: LEGAL IN CALIFORNIA ONLY FOR RACING VEHICLES WHICH MAY NEVER BE USED, OR REGISTERED OR LICENSED FOR USE, UPON A HIGHWAY.
This product is legal for closed-course competition use only; for racing vehicles (a competition vehicle not used on public highways). Intended for off-road use or race purposes; does not meet regulations of pollution controlled roads or highways. This system is NOT compliant with the California Environmental Protection Agency (E.P.A.) or California Air Resources Board (C.A.R.B) for use on public roads or lands.
